FS-Curtis NXB06 – 7.5 HP Rotary Screw Air Compressor with Integrated Air Dryer
Base Mounted | Integrated Refrigerated Dryer | Tri-Voltage 3-Phase or 230V Single-Phase
The FS-Curtis NXB06 with Integrated Air Dryer delivers dependable rotary screw performance and clean, dry compressed air in one compact, factory-integrated package. Designed for shops and light industrial operations that require higher airflow and moisture control, this 7.5 horsepower fixed-speed rotary screw compressor with built-in refrigerated dryer simplifies installation while protecting your air system.
By integrating the refrigerated dryer directly into the compressor package, the NXB06 reduces floor space, piping complexity, and installation time — while ensuring consistent air quality at the source.
Continuous-Duty Rotary Screw Performance
Engineered for 100% continuous duty, the NXB06 provides steady, pulsation-free airflow with lower oil carryover compared to reciprocating compressors.
-
7.5 HP Fixed Speed Rotary Screw Compressor
-
Integrated Refrigerated Air Dryer
-
Air Delivery Performance:
-
29 CFM @ 100 PSI
-
27 CFM @ 125 PSI
-
24 CFM @ 150 PSI
-
22 CFM @ 175 PSI
-
-
Quiet Operation: Approximately 67 dBA
-
Smooth, Consistent Airflow for Tools & Equipment
The integrated dryer removes moisture before it enters your air lines, helping prevent corrosion, tool damage, paint defects, and unnecessary maintenance.
Electrical & Pressure Configuration Options
To ensure flexibility across a wide range of facilities, the NXB06 with integrated dryer is available in:
-
Tri-voltage 3-phase: 208V / 230V / 460V
-
230V single-phase option
-
Pressure options ranging from 100 to 175 PSI
This versatility allows the compressor to integrate seamlessly into commercial, light industrial, and shop environments without costly electrical upgrades.
Optional iCommand Touch+ Controller
For customers who want enhanced system control and monitoring, the optional iCommand Touch+ controller adds advanced intelligence:
-
7-inch full-color touchscreen interface
-
Advanced diagnostics and fault history
-
Performance monitoring and trend tracking
-
Service reminders and system protection features
-
Improved operational efficiency and compressor control
NXGEN Extended Warranty Program
The FS-Curtis NXB06 is backed by the NXGEN Extended Warranty Program, delivering industry-leading protection and long-term peace of mind. When properly registered and maintained using genuine FS-Curtis parts and lubricants, coverage includes:
-
Five-year warranty on major components
-
Ten-year warranty on the rotary screw airend
Why Buy from Compressed Air Advisors Online?
Compressed Air Advisors Online is America’s choice for compressed air solutions, providing nationwide expertise to ensure your system is properly sized and configured. We help customers select the correct voltage, pressure, and air treatment setup so their investment performs reliably from day one.
If you have questions about system layout, moisture control, or electrical requirements, our compressed air specialists are ready to help.
