Hertz HBD 18 TMD Rotary Screw Air Compressor – 25 HP Tank Mount with Dryer, 119 CFM

(0)
$23,516.00
$23,516.00
$26,100.00
Sold out
Quantity must be 1 or more

Hertz HBD 18 TMD Tank Mount Rotary Screw Air Compressor with Dryer

The Hertz HBD 18 TMD Tank Mount Air Compressor with Dryer is built for businesses that demand reliable compressed air and a clean, dry air supply in one compact package. Designed with Hertz’s proven belt-driven rotary screw technology, this 18.5 kW / 25 HP compressor delivers powerful performance, quiet operation, and reduced maintenance—making it the perfect fit for small to medium industrial applications.

Key Features & Benefits

  • All-in-One Package: Integrated refrigerated air dryer and ASME-rated air receiver ensure clean, dry compressed air without the need for multiple machines.

  • Factory-Configurable Pressure Options: Ships standard at 125 PSI, with factory settings available for 100, 150, or 175 PSI to meet your system requirements.

  • Strong Air Delivery: Produces up to 119 CFM at 100 PSI and 106 CFM at 125 PSI, delivering consistent air flow for demanding production environments.

  • Premium Components: Equipped with an IE3 efficiency class IP55 motor, wye-delta starter, and Hertz’s high-efficiency screw block for long-lasting, energy-efficient performance.

  • Service Friendly: Features quick-release panels, spin-on air/oil separator, and easy belt-tensioning system to minimize downtime and reduce maintenance costs.

  • Quiet Operation: Operates at just 72 dB(A), making it suitable for installation directly in your facility without excessive noise disruption.

  • Built to Standards: UL-certified electrical components and ASME-compliant tanks for safety and code compliance.

Technical Specifications

  • Model: Hertz HBD 18 TMD (Tank Mount with Dryer)

  • Motor Power: 18.5 kW / 25 HP

  • Capacity: 88–119 CFM (depending on pressure setting)

  • Operating Pressure: 100 / 125 / 150 / 175 PSI (factory configurable)

  • Noise Level: 72 dB(A)

  • Dimensions (L x W x H): 50" x 34" x 58"

  • Weight: 1,102 lbs
