Hertz Kompressoren HDD 30 – 40 HP Direct-Drive Rotary Screw Air Compressor
Power. Precision. Proven Hertz Reliability.
The Hertz Kompressoren HDD 30 – 40 HP rotary screw air compressor is designed for businesses that need dependable compressed air without compromise. This oil-injected, direct-drive system delivers exceptional energy efficiency, low operating noise, and industrial-grade reliability — all backed by Hertz’s legendary engineering and innovation.
Efficient Performance You Can Trust
The HDD 30 Series delivers up to 207 CFM @ 100 PSI, providing smooth, consistent airflow for demanding industrial and manufacturing applications. The direct-coupled IE4 IP55 motor eliminates belt losses, reducing maintenance costs while maximizing efficiency and longevity.
Smart Cooling and Rugged Durability
Featuring independent radiator segments and a low-speed radial cooling fan, this compressor keeps internal temperatures low and stable — even in harsh environments up to 113°F ambient. A precision-machined screw block with next-generation rotor profiles ensures reduced torque requirements, quieter operation, and long-term reliability.
Intelligent Control System
Equipped with a user-friendly controller, the HDD 30 allows real-time monitoring of operating conditions, load/unload cycles, and maintenance intervals. It supports ModBus communication and Master/Slave synchronization for two-compressor systems, making it a perfect choice for multi-unit installations or expanding facilities.
Simplified Maintenance
Removable hinged panels and a hinged oil tank cover provide fast, easy service access. The quick-service coupling system enables maintenance on the drive assembly in under 30 minutes — minimizing downtime and keeping your operation running at peak efficiency.
Key Specifications
-
Horsepower: 40 HP (30 kW)
-
CFM: 207 @ 100 PSI | 183 @ 125 PSI | 162 @ 150 PSI | 140 @ 175 PSI
-
Pressure Range: 100 – 175 PSI
-
Voltage: 460 V / 3 Phase (Stocked) — Convertible to 230 V / 3 Phase
-
Cooling: Independent Radiator + Radial Fan
-
Drive System: Direct-Coupled
-
Motor Efficiency: IE4 / F-Class Insulated
-
Controller: LCD Display with ModBus & Scheduler
-
Dimensions: 78" L × 44" W × 64" H
-
Weight: ≈ 2,248 lbs
Why Buy from Compressed Air Advisors Online
Every Hertz Kompressoren HDD Series Rotary Screw Air Compressor purchased through Compressed Air Advisors Online includes a Free Factory-Authorized Start-Up and Warranty Validation. We make sure your investment performs exactly as intended — from installation to operation — with nationwide support and expert guidance.
