Hertz Kompressoren HDD 75 – 100 HP Direct-Drive Rotary Screw Air Compressor
Heavy-Duty Power. Ultimate Reliability. Engineered for Industrial Excellence.
When your operation demands continuous, high-volume air with uncompromising efficiency, the Hertz Kompressoren HDD Series 75–100 HP delivers. Built for heavy-duty industrial environments, this direct-coupled, oil-injected rotary screw compressor is engineered for superior performance, low energy consumption, and unmatched durability.
Unstoppable Performance
Powered by a high-efficiency IE4 IP55 electric motor, the HDD Series delivers up to 495 CFM at 100 PSI. The direct-drive coupling ensures zero belt slippage and minimal transmission losses, translating to lower operating costs and extended lifespan.
Advanced Cooling & Durability
With independent radiator segments and a slow-speed radial fan, the HDD Series maintains optimal internal airflow even in ambient temperatures up to 113°F. Flexible coupling joints and a precision-balanced oil-injected screw block reduce vibration, wear, and torque requirements—ensuring years of trouble-free operation.
Intelligent Control System
The integrated smart controller allows Master/Slave operation of up to two compressors, internal ModBus communication, and a weekly scheduler for energy-efficient automation. For 75 HP and above, you also get maintenance logs, history tracking, and customizable alarm alerts for maximum control and uptime.
Built for Ease of Service
Designed for maintenance simplicity, the HDD Series features hinged panels, a quick-access oil tank cover, and a 30-minute coupling service system, allowing faster routine checks and reduced downtime.
Key Specifications
-
Horsepower: 75–100 HP
-
Capacity: Up to 495 CFM @ 100 PSI
-
Pressure Range: 100–175 PSI
-
Drive System: Direct-Coupled
-
Cooling: Independent Radiator + Radial Fan
-
Electrical Motor: IE4 Efficiency / F-Class Insulation
-
Controller: Smart PLC Interface w/ Scheduler & ModBus
