FS Curtis DA Series Desiccant Modular Air Dryers -40 F Dew Point
DA SERIES – MODULAR DESICCANT COMPRESSED AIR DRYERS
DA Series offers compressed air users a simple and effective no-nonsense approach to dry compressed air. Great for use with any type of compressor including piston, scroll, rotary vane or rotary screw technologies. The ability to function with inlet temperatures to 150 F makes it ideal for use with tank mounted reciprocating air compressors that lack an aftercooler.
Protect compressed air lines from oil, water and particulate
The easy to maintain the DA Series is a compact heatless desiccant air dryer which delivers high quality compressed air capable of achieving superior pressure dew points -40°F or lower. Use the DA Series when precision work requires high quality air.
Reduce energy and operating costs with DA Series.Contaminated compressed air lines drags down productivity, raises operating costs, and increases maintenance requirements.
DA Series benefits include:
Requires less electrical usage than alternatives
Extends service life of pneumatic driven devices
Avoid expensive downtime to repair or replace equipment
Reduces prep time in spray applications
Eliminates rework due to compressed air contaminants
Modular design allows for quick, easy and flexible expansion
Listed are types of operationsthat significantly reduced operating costs
Paint/foam spraying
Sand/shot blasting
Air tools
Vehicle wash stations
Packing equipment
Lab measurement equipment
Drilling equipment
Railcar braking systems & Loci’s
Mining car dump stations
Dust collection systems
Baghouse equipment
Bottling equipment
Plasma cutting
Drag line shovels
Batch mixing
Rail maintenance equipment
Simple and easy to service:Maintenance personnel can easily spin off the desiccant cartridges and replace service components in a matter of minutes.
Designed for outdoors- complies with NEMA 4 Standard - when equipped with thermostaticallycontrolled heater package keeps dryer performing during winter months.
The DA Series Dryer can be wall mounted or compressor mounted.
*Models DA-220E, 230E, 240E include mounting brackets.
Easy installation (universal wall mounting brackets) in a compact and expandable system, wall or compressor mounted
Can be mounted on most compressors
Alternative to a high inlet temperature refrigerated dryer
Environmentally friendly, using no refrigerant
Lowest operational and maintenance cost of any regenerative air dryer
Molecular sieve desiccant in easy spin-on canisters
Particulate after filter built into the canisters
Operates uninterrupted in dirty or dusty environments
150˚F maximum inlet temperature
Air cooled aftercooler not required
Additional options available
* Coalescing Prefilter with automatic drain is recommended.
