Description
Champion HR5-3 – R-Series 5 HP Two-Stage Reciprocating Air Compressor | 30-Gallon Horizontal Tank
Available Voltages: 208–230 V / 3 Ph, 230 V / 1 Ph, and 460 V / 3 Ph
CFM @ 175 PSI: 17.0
RPM: 737
Tank Size: 30-Gallon Horizontal
Model: HR5-3
Compressor Pump: R-15B
Warranty: 1-Year Standard / 3-Year Pump Warranty (Option for 6-Year Extended with Premium Kit)
Compact Size. Heavy-Duty Performance.
The Champion HR5-3 delivers professional-grade compressed-air performance in a compact footprint. Built in the USA and part of Champion’s legendary R-Series, this 5 HP, two-stage, splash-lubricated compressor produces 17 CFM @ 175 PSI, giving you the air volume and pressure needed for body shops, manufacturing facilities, and woodworking environments that demand dependable power.
Its R-15B cast-iron pump runs cool and quiet, with balanced pistons, tapered roller bearings, and a gasket-free head design to prevent leaks. Loadless-start technology ensures smooth, reliable motor starts and longer service life. Rugged, reliable, and easy to service—the HR5-3 is engineered for long-term industrial performance.
Key Features
-
Rugged R-15B Pump: Two-cylinder, two-stage cast-iron pump with domed pistons for high efficiency and long life.
-
Splash Lubricated Design: Proven reliability with minimal maintenance requirements.
-
Loadless Start Unloader: Reduces motor wear and energy consumption by starting the compressor unloaded every time.
-
ASME-Certified 30-Gallon Tank: Industrial-grade, horizontal receiver built for safety and durability.
-
Flexible Voltage Options: Available in 208–230 V / 3 Ph, 230 V / 1 Ph, and 460 V / 3 Ph configurations.
-
Upgradeable Accessories: Add air-cooled aftercooler, automatic drain, low-oil stop control, or vibration isolators for enhanced protection.
-
Extended Protection Available: Upgrade to Champion’s Premium Maintenance Kit for 6 years pump coverage and 2 years package coverage.
Performance Specifications
| Specification |
HR5-3 |
| Horsepower |
5 HP |
| Pump Model |
R-15B |
| Tank |
30-Gallon Horizontal |
| CFM @ 175 PSI |
17.0 |
| RPM |
737 |
| Voltage |
208–230 V / 3 Ph, 230 V / 1 Ph, 460 V / 3 Ph |
| Weight |
432 lbs |
| Dimensions (L × W × H) |
43″ × 32″ × 44″ |
| Warranty |
1-Year Package / 3-Year Pump |
Why Buy from Compressed Air Advisors Online
At Compressed Air Advisors Online, we’re proud to be America’s choice for compressed air solutions—offering nationwide expertise, fast shipping, and industry-leading brands like Champion. Whether you’re upgrading your existing setup or building a new system, our team provides expert guidance to ensure you get the right compressor for your operation.
💨 Free Freight Across the Continental U.S.
🔧 Professional Advice from Compressed Air Experts
📦 Nationwide Delivery and Support
The Champion HR5-3—small footprint, big performance, and built to run for decades.
