Description

Champion VR5-8 – R-Series 5 HP Two-Stage Reciprocating Air Compressor

17 CFM @ 175 PSI | 80-Gallon Vertical Tank | Industrial Duty Performance

The Champion VR5-8 R-Series 5 HP two-stage reciprocating air compressor delivers 17 CFM at 175 PSI and is built for shops that expect dependable compressed air every single day. Designed around Champion’s slow-speed R-15B splash-lubricated compressor pump operating at 737 RPM, this rugged industrial piston compressor provides long service life, cooler operating temperatures, and consistent airflow for demanding applications.

Mounted on a heavy-duty 80-gallon vertical ASME air receiver, the VR5-8 is ideal for automotive facilities, woodworking shops, fabrication environments, maintenance departments, and light manufacturing operations that require reliable high-pressure compressed air with extended duty capability.

Champion’s R-Series compressors have earned their reputation over decades by delivering dependable performance, easy maintenance access, and durable cast-iron construction that keeps operations running smoothly shift after shift.

Key Features

17 CFM @ 175 PSI Output
Reliable airflow for professional shop and industrial compressed air applications.

Slow-Speed 737 RPM Compressor Pump
Lower heat, reduced vibration, and longer component life.

Load-Less Start (Centrifugal Unloader)
Reduces motor strain and improves startup reliability.

Mounted Control Panel with Magnetic Starter
Simplifies installation while providing motor protection.

80-Gallon Vertical ASME Air Receiver
Compact footprint with increased air storage capacity.

Industrial ODP NEMA 1760 RPM Motor
Designed for continuous shop operation.

Integral Cylinder / Head Design
Eliminates head gasket failures for improved reliability.

High-Flow Corrosion-Resistant Disc Valves
Efficient airflow with long service life.

Balanced Crankshaft with Oversized Bearings
Smooth operation and reduced mechanical wear.

Precision Flywheel Cooling Fan
Maximizes airflow across intercoolers for cooler operation.

ASME Inter-Stage Pressure Relief Valve
Additional protection for safe operation.

10-Micron Industrial Intake Filter
Protects pump components from airborne contaminants.

Engineered for Real-World Shop Performance

The Champion R-15B compressor pump inside the VR5-8 uses a splash-lubricated cast-iron design with tapered roller bearings, balanced pistons, and large finned intercoolers to deliver consistent airflow while minimizing maintenance demands. Its slow rotational speed helps extend valve life, bearing life, and ring performance compared to high-RPM alternatives.

This design philosophy keeps your compressed air system steady, predictable, and ready when production depends on it.

Ideal Applications

Automotive repair shops
Woodworking and cabinet manufacturing
Maintenance departments
Fabrication facilities
Light industrial production environments
General service garages
Body shops and finishing operations

Technical Specifications

Model: Champion VR5-8
Horsepower: 5 HP
Pump Type: Two-Stage Reciprocating (Splash-Lubricated)
CFM: 17 CFM @ 175 PSI
Maximum Pressure: 175 PSI
Pump RPM: 737 RPM
Tank Size: 80 Gallon
Tank Orientation: Vertical
Motor Type: ODP NEMA 1760 RPM
Control Panel: Mounted Magnetic Starter Included
Voltage Options:
Single Phase 208–230V
Three Phase 208–230 / 460V
Receiver Certification: ASME
Tank Pressure Gauge: 0–300 PSIG

Warranty Coverage

Includes Champion’s 3-Year Non-Pro-Rated Pump Warranty

Optional 6-Year Extended Warranty Kit available when purchased with the compressor and maintained according to factory service intervals.
