Description

FS-Curtis NXB15 – 20 HP Rotary Screw Air Compressor with Integrated Air Dryer

Base Mounted | Integrated Refrigerated Dryer | Tri-Voltage 3-Phase | Optional iCommand Touch+

The FS-Curtis NXB15 with Integrated Air Dryer delivers high-capacity rotary screw performance combined with factory-integrated air treatment in one compact, efficient package. Designed for facilities that require strong airflow and dependable moisture control, this 20 horsepower fixed-speed rotary screw compressor provides clean, dry compressed air while minimizing installation time and system complexity.

By incorporating a refrigerated dryer directly into the compressor package, the NXB15 reduces footprint, simplifies piping, and ensures consistent air quality at the source.

High-Capacity Continuous-Duty Performance

Engineered for 100% continuous duty, the NXB15 produces smooth, pulsation-free airflow with reduced oil carryover compared to reciprocating compressors. It is built to support demanding shop and industrial applications that require stable and reliable compressed air delivery.

• 20 HP Fixed Speed Rotary Screw Compressor

• Integrated Refrigerated Air Dryer

• Air Delivery Performance:

  • 82 CFM @ 100 PSI

  • 77 CFM @ 125 PSI

  • 72 CFM @ 150 PSI

  • 62 CFM @ 175 PSI

• Quiet Operation Suitable for Shop Environments

• Consistent Airflow for Tools, CNC Equipment & Production Systems

The integrated dryer removes moisture before it enters downstream piping, helping prevent corrosion, tool damage, and finish defects in painting or coating applications.

Why Choose an Integrated Dryer System?

Moisture is one of the leading causes of compressed air system issues. The NXB15 integrated system provides:

• Cleaner, drier air at the source

• Reduced condensation in piping

• Improved equipment longevity

• Better finish quality in coating and finishing operations

• Simplified installation compared to separate compressor and dryer setups

• Reduced overall footprint

This configuration is ideal for manufacturing facilities, automotive shops, CNC operations, and woodworking environments where air quality impacts performance and productivity.

Electrical & Pressure Configuration Options

The NXB15 with integrated dryer is available in:

• Tri-voltage 3-phase: 208V / 230V / 460V

• Pressure options ranging from 100 to 175 PSI

This versatility allows seamless integration into a wide range of commercial and industrial electrical systems.

Optional iCommand Touch+ Controller

For enhanced monitoring and control, the optional iCommand Touch+ controller provides advanced system intelligence:

• 7-inch full-color touchscreen interface

• Advanced diagnostics and fault history

• Performance monitoring and trend tracking

• Service reminders and compressor protection features

NXGEN Extended Warranty Program

The FS-Curtis NXB15 is backed by the NXGEN Extended Warranty Program, delivering industry-leading protection and long-term peace of mind. When properly registered and maintained using genuine FS-Curtis parts and lubricants, coverage includes:

• Five-year warranty on major components

• Ten-year warranty on the rotary screw airend

Why Buy from Compressed Air Advisors Online?

Compressed Air Advisors Online is America’s choice for compressed air solutions, offering nationwide expertise to ensure your compressor system is properly sized and configured. We help customers select the correct voltage, pressure, and air treatment configuration so their investment performs reliably from day one.

If you have questions about airflow requirements, moisture control, or system configuration, our compressed air specialists are ready to help.
