Hertz Kompressoren HVD37 - 50hp Variable Speed Rotary Screw Air Compressor, Base Mount, 237 SCFM @ 125 PSI

$19,915.00

Sku: 6001700102

- Select Voltage

Voltage
- +
Free Shipping

On All Orders Over $149.00

Satisfaction Guaranteed

Easy Exchanges & Returns

Secure checkout

Protected By SSL

As low as /month for 36 months or /month for 48 months

Overview
Description

HVD SERIES
Variable Speed Rotary Screw Air Compressor

Hertz HVD Series Variable Speed Compressors are and excellent choice when your facility demands reliability performance and an air compressor that can be easily maintained.

HERTZ HVD series variable-speed compressors drive the motor with the frequency converter to adjust the compressor operation speed according to compressed air requirements and save up to 35% energy. Thanks to its high-quality equipment and excellent engineering in its design, it provides a very efficient and flexible use as per requirements.

STANDARD EQUIPMENT

High quality components such as IP55 electric motors with the IE3 efficiency class, IP54 fan motors, star-delta motor starter system, electrical materials selected according to IEC, UL/cUL, CE standards as per the market requirements, high-efficiency screw blocks consuming less energy are provided as standard in all Hertz Kompressoren compressors.

Serviceability

Service-friendly design implemented using a layout that provides instant access to all consumable items, with quick-release protective covers and easy-to-use
controllers minimizes downtime and reduces maintenance costs.

ELECTRONIC CONTROL

Hertz Kompressoren rotary screw compressors are equipped with easy-to-use, robust and long-lasting microprocessor controllers with communication capabilities as per the product line to ensure smooth operation and uninterrupted production.

SCREW BLOCK

  • Patented and durable screw block that provides high-capacity of air, and that is specially selected for each model’s capacity requirement
  • Production of air with less loss of air, thanks to the new rotor profiles, and lower torque requirements
  • New generation bearing design with increased load carrying capabilities

AIR OIL SEPARATOR

Spin-on or immersed type separator design depending on the product line
Immersed type separator

  • High performance separation with three-stage design
  • More efficient separation at lower volume with deeply wrapped, intertwined separation layers
  • Low amount of oil mist in outlet air ≤ 3 ppm

Spin-on separator

  • Easy replacement, ease of assembly and disassembly
  • Design that does not require a separator tank

MAIN MOTOR AND DRIVE SYSTEM

Premium 230/460V/3 phase/60Hz, IE3 IP55 electric motors with F Class insulation, Wye-Delta motor starting system,  Long-lasting and efficient transfer system thanks to use of elastic couplings on direct coupled models.

ADVANTAGES

  • Up to 35 % energy saving*
  • Operation at constant output pressure value
  • Wide operating pressure range (100-175 psi)
  • Soft starting
  • Protection against the adverse effects of peak currents
  • *When compared with compressors without an inverter for business

MAIN MOTOR AND DRIVE SYSTEM

  • Directly coupled one on one (1:1) with the elastic coupling
  • Variable-speed starting with frequency converter
  • High temperature protection with motor bearings
