Tsunami - Filter-Regulator-Lubricator, 1/4″port, 25 SCFM (F/R/L), PN:8825701
On All Orders Over $149.00
Easy Exchanges & Returns
Protected By SSL
Tsunami's Filter-Regulator-Lubricator offers reliable air treatment in a single stage unit. The 1/4" port ensures a flow rate of up to 25 SCFM for efficient operation. PN:8825701.
Tsunami™ Filter-Regulator-Lubricator, 1/4″port, 25 SCFM (F/R/L)
These combination Filter/Regulator units are designed for single-station applications. Use one at each air drop to adjust flow for each pneumatic tool for optimal performance and protection. Each head has a port for inclusion of a pressure gage.
These filters offer 20 micron particulate filtration. Quick-Twist release manual drain.
The Tsunami™ Pressure Regulator is an all metal, highly reliable, heavy duty piston regulator. Piston regulators offer higher flow rates than standard diaphragm units. Tsunami™ Pressure regulators also have excellent set pressure stability.
The Tsunami™ Lubricator is powder coated Zamak construction with clear Nylon sight slots and delivers a very high quality proportional flow of lubricant per SCFM of air. Lubricator uses a micrometric regulation effect to dispense oil into the air stream. This method ensures lubrication at a very low flow as well as at very high flow. Adjustment is achieved by turning the slotted needle located inside the flow gage on the head.
Port Size - 1/"
Max Flow: 25 SCFM
Setting Range: 0-160 PSI
